Hose pump for the food industry

Sanitary version that is fully suitable and compatible for pumping food products and complies with current specifications and regulations.

Sanitary design which optimises downtime, makes the cleaning process easier and improves efficiency.

The manufacturing process of the hose in FDA food grade nitrile provides extra resistance to temperature and extends the useful working life.

DIN 11851 or Triclamp food grade connections with a stainless steel base and front cover.

The front cover can be easily and quickly removed to make the clean-in-place (CIP) cleaning and front roller extraction processes easier.

Technical specifications

F28

FLOW RATE RANGE 5 to 20.000 l/h

MAXIMUM PRESSURE 10 bar

INNER DIAMETER 13 to 70 mm

MATERIAL OF CONNECTIONS AISI-316L stainless steel

CONNECTION TYPES DIN 11851, Tri-clamp

MATERIAL OF ROLLERS Hard aluminium (anodised)

MAX. TEMPERATURE 80ºC

MATERIAL OF HOSE NBR (Food grade)
